 Apex 서보용 감속







AE  Series

  • 저렴한 가격
  • Size: AE050 / AE070 / AE090 / AE120 / AE155/ AE205/          AE235
  • 감속비: 1 stage     3 / 4 / 5 / 6 / 7 / 8 / 9/10

                      2 stage    15/20/25/30/35/40/45

                       50/60/70/80/90/100

  • Backlash
                1 stage : ≤8 arcmin
                2 stage : ≤12 arcmin




AER  Series

  • Size: AER050 / AER070 / AER090 / AER120 / AER155 /          AER205 / AER235
  • 감속비: 1 stage    3/4/5/6/7/8/9/10/14/20

                      2 stage   15/20/25/30/35/40/45/50/

                     60/70/80/90/100/120/140/

                    160/180/200

  • Backlash
                1 stage : ≤10 arcmin
                2 stage : ≤14 arcmin




AB  Series
  • 낮은 Backlash

  • Size: AB042 / AB060 / AB090 / AB115 / AB142 / AB180 /          AB220
  • 감속비: 1 stage     3 / 4 / 5 / 6 / 7 / 8 / 9/10

                      2 stage    15/20/25/30/35/40/45

                      50/60/70/80/90/100

  • Backlash
                1 stage : ≤1arcmin / ≤3arcmin / ≤5arcmin
                2 stage : ≤3arcmin / ≤5arcmin / ≤7arcmin




ABR  Series

  • Size: ABR042 / ABR060 / ABR090 / ABR115/ ABR142 /          ABR180 / ABR220
  • 감속비: 1 stage    3/4/5/6/7/8/9/10/14/20

                      2 stage   15/20/25/30/35/40/45/50/

                     60/70/80/90/100/120/140/

                    160/180/200

  • Backlash
                1 stage : ≤2arcmin / ≤4arcmin / ≤6arcmin
                2 stage : ≤4arcmin / ≤7arcmin / ≤9arcmin




AF Series

  • 강력한 동력전달 (테이퍼 롤러 베어링)

  • Size: AF042 / AF060 / AF075 / AF100 / AF140 / AF180 /          AF220
  • 감속비: 1-stage :    3 / 4 / 5 / 6 / 7 / 8 / 9 / 10

                      2-stage :  15 / 20 / 25 / 30 / 35 / 40 / 45 / 50 /

                                      60 / 70 / 80 / 90 / 100

  • Backlash
                1-stage : ≤1arcmin / ≤3arcmin / ≤5arcmin
                2-stage : ≤3arcmin / ≤5arcmin / ≤7arcmin




AFR  Series

  • Size: AFR042 / AFR060 / AFR075 /AFR100 / AFR140 /          AFR180 / AFR220
  • 감속비: 1 stage    3/4/5/6/7/8/9/10/14/20

                      2 stage   15/20/25/30/35/40/45/50/

                     60/70/80/90/100/120/140/

                    160/180/200

  • Backlash
                1 stage : ≤2arcmin / ≤4arcmin / ≤6arcmin
                2 stage : ≤4arcmin / ≤7arcmin / ≤9arcmin
